Drucker HORIZON 6 Flex Fixed-Angle Routine Centrifuge

The Drucker HORIZON 6 Flex Fixed-Angle Routine Centrifuge is a compact, programmable centrifuge designed for flexible fixed-angle processing in routine laboratories.

Features:

• Compact Size - Fits tight spaces with a compact 1.16ft² footprint
• Default Presets - Use default presets for chemistry, coag, and urine, or program your validated cycles
• Easy to Use - Use the simple, two-button interface to select a preset, or program and record your validated settings on the included label. Stores up to 10 custom cycles using the digital display
• Easy to Monitor - Monitor RPM and time remaining down to the very last second on the digital display. LED lid lighting is off when the centrifuge is ready, on when running, and flashing at the end of the cycle
• Built to Last - No routine maintenance. Brushless motor, engineered composite components
• Engineered for Safety - Protect your lab with imbalance detection and a shatterproof lid that can only be opened when the rotor is stopped, even if the unit loses power
• Fixed-Angle - The rotor remains at a 45° angle during sample processing
• Positive Lid Latching - Firm mechanical latching of the lid prevents the escape of debris
• Clear Shattered Proof Lid - Allows for safe sample observation and optical calibrations
• Reinforced Guard Bowl - Provides maximum safety and durability
• QR Code - For easy access to support videos, manuals, and more
• Designed, built, and supported in the USA
• Certified to USA, Canadian, and European safety regulations and standards
• Comes Standard with:
  • (1) Fixed-angle rotor
  • (6) 16 x 100 mm blue carrier (7713079K)
  • (6) 16 x 125 mm orange carrier (7713044K)

Technical Specifications:

• Maximum Capacity: 6 samples up to 15 mL
• Tube Sizes:
  • Up to 16 x 100 mm or 10 mL
  • Up to 16 x 125 mm or 15 mL
  • Up to 10 x 46 mm or 2 mL (with adapter sold separately)
• Maximum RPM: 3,800 RPM
• Maximum G-Force: 2,000 xg
• Centrifuge Motor: 1/2 H.P. Brushless
• Sound Level: 64 dBA
• Factory Settings Range: 1 to 30 minutes (±1%)
• Supply Voltage: 100 - 240 (±10%) VAC
• Supply Frequency: 50/60 Hz
• Current Consumption: 2.2 A at 115 VAC
• Environmental Conditions:
  • Set-Up Site: Indoor Use Only
  • Altitude: Up to 2,000 meters from sea level
  • Ambient Temperature: 5°C to 40°C
  • Humidity: Maximum relative humidity 80% for temperatures up to 31°C, decreasing linearly to 50% relative humidity at 40°C
  • Overvoltage Category: II
  • Pollution Degree: 2
• Standard Preset Cycles:
  • Cycle 1 (Chemistry): 10 minutes / 3,900 RPM / 1,600 xg (with blue carrier) / 1,850 xg (with orange carrier)
  • Cycle 2 (Coag, PPP): 15 minutes / 3,800 RPM / 1,500 xg (with blue carrier) / NA (with orange carrier)
  • Cycle 3 (Urine): 5 minutes / 2,200 RPM / 500 xg (with blue carrier) / 600 xg (with orange carrier)
• Applications: Blood chemistry, pediatric samples, fecal, and urine
• Tubes Most Often Used: Kova tubes, lithium heparin (with gel), lithium or sodium heparin (without gel), serum (without gel), sodium citrate, urinalysis ( with conical bottom), urine chemistry (with rounded bottom)
• Warranty: 2 Years (Extended warranty options are available)
• Overall Dimensions: 14" D x 12" W x 9" H
• Actual Product Weight: 12 lbs

*Please Note: Tubes are sold separately.
