15" x 18" X-Ray Grid
Product Description
The 15" x 18" X-ray Grids provide clearer radiograph images by trapping scattered radiation, the biggest contributing factor to poor diagnostic quality. Introducing an x-ray grid between the x-ray beam and the film or plate will provide a clearer and more detailed image.
Choosing the Right Grid
| Cleanup | Ratio/Type | Positioning Latitude | Recommended Up To | Remarks |
| SUPERLATIVE | 8:1 criss-cross | Distance fair; centering and leveling sight | 120 KVP | Not recommended for tilted tube technique |
| EXCELLENT | 12:1 linear | Very slight | 110 KVP (Suitable for higher KV) | Extra care required for proper alignment; usually used in fixed amount |
| EXCELLENT | 6:1 criss-cross | Good | 100 KVP | Tube tilt limited to five degrees |
| GOOD | 8:1 linear | Distance fair; centering and leveling-slight | 100 KVP | For general stationary grid use |
| GOOD (CR) | 4:1, 6:1 | Good | 120 KVP | CR Grid |
| MODERATE | 6:1 linear | Good | 80 KVP | Least expensive of stationary grids |
| Anatomy | Lines Per Inch | Ratio | Distance |
|---|---|---|---|
| SKULL | 103 | 10:1 | 36-40" |
| CHEST | 103-150 | 10:1-12:1 | 60-72" |
| CR CHEST | 150, 178 | 4:1, 6:1 | Parallel |
| ABDOMINAL | 103 | 8:1 | 34-44" |
| CR ABDOMINAL | 150, 178 | 4:1, 6:1 | Parallel |
| SCOLIOSIS STUDIES | 85-103 | 8:1 | 48-72" |
| Special Procedures | |||
| MOST STUDIES | 103 | 10:1 | 36-40" |
| BI-PLANE | 103 criss-cross | 10:1 | 36-40" |
| Surgical Room | |||
| ORTHOPEDICS | 85 | 8:1 | 34-44" |
| CHOLANGIOGRAMS VENOUS STUDIES | 103 | 8:1, 10:1 | 34-44, 36-40" |
| Emergency Room | |||
| TRANS LATERAL SKULL, SPINES, HIPS | 85-103 | 6:1-8:1 | 34-44" |
About this Brand
Since 1991, RC Imaging has been a leading manufacturer of innovative imaging accessories for diagnostic imaging professionals. Their extensive portfolio of radiology equipment is focused on DR panel protection, weight bearing devices, positioning aids, and anti-scatter grids.
Specifications
| Manufacturer | RC Imaging |
|---|---|
| Country of Manufacture | South Korea |
| Item Ships From | New York |
