Microscope Ultra HD-4K Camera with 1/1.8" Sony 4K Sensor
-
Oxion Inverso Trinocular Inverted Microscope, HWF Plan 10x/22mm Eyepieces, Quintuple Nosepiece with Plan Phase PLPH, Mechanical StageMSRP $4,527.00 MSRP $4,527.00 $4,172.00 -
Oxion Inverso Trinocular Inverted Microscope, HWF Plan 10x/22mm Eyepieces, Quintuple Nosepiece with Plan Phase PLPH, Mechanical Stage, CMEX-18 Pro CameraMSRP $5,088.00 MSRP $5,088.00 $4,689.00
Product Description
The Ultra HD-4K Camera with 1/1.8" Sony 4K Sensor offers a new solution to modern microscopy for industry and laboratories where more spatial detail and contrast is needed. With the latest horizontal display resolution of 3,840 pixels (2,160p) and new 4K screens, this UHD image quality camera can be used for biological, metallurgical or stereo microscopes. It provides excellent color rendering at high frame rates, with up to 60 frames per second.
Features:
-
Ultra HD 2160p, 8.3 MP, 1/8-inch color 4K Sony sensor
-
3840 x 2160 pixels, 30 fps, H264 codec
-
4K HDMI 2.0 standard
-
Real time images directly on TV, monitor or beamer
-
Stand-alone with built-in mouse-driven software
-
Can be used via PC (computer-controlled mode)
-
Interface: HDMI, USB-2, Ethernet, Wi-Fi
-
Works with ImageFocus Alpha software
-
ADC 16 bits, color depth 36 bits
-
C-mount interface
-
2061p/1080p automatic switching
-
SD memory card included
Technical Information:
| Model | UHD-4K |
| Sensor | 4K Sony |
| Format | 1/1.8", HDTV 2160p |
| Pixel Size | 2.0 x 2.0μm |
| Pixels |
3840 x 2160 (capture mode) HDMI 30fps, USB 30fps |
| Video | 2160 pixels video recording mode |
| ScanMode | Progressive scan, rolling shutter |
| Noise | Standard noise reduction |
| Sensitivity Lux/sec | 505mV |
| Color Rendering | 36 bits |
| Exposure | Automatic/manual |
| White Balance | Automatic/manual/ROI |
| Signal/Noise Max | 40.5 db |
| Interfaces | HDMI, USB-2.0, Ethernet, WiFi |
| Data Storage | High-speed 32GB SD memory card |
| Camera Buttons | On/Off |
| Mounting | C-mount interface |
| Power Supply | 100-240VAC to 12VDC/1A |
| Humidity | 30 - 80% |
| Operation Temperature | -10 – 50° Celsius |
| Storage Temperature | -20 – 60° Celsius |
| Measurement | Supported |
| Supplied With | 30mm and 30.5mm adapters for stereo microscopes, 12 V/1 A power adapter, 32GB SD card, Micro USB Synchronous cable 1.5M, HDMI cable, USB mouse, WiFi dongle, 76 x 24mm calibration slide (1mm/100), carton box |
| PC Software | Works with ImageFocus Alpha imaging and measuring software for Windows 10/11 (32 and 64-bit configurations) and Linux. A macOS version is also available (with a few differences in features) |
| PC Requirements | Compatible with Intel Core 2, 2.8GHZ or higher, 2GB, USB-2 |
Specifications
| Manufacturer | Globe Scientific |
|---|---|
| Country of Manufacture | China |
| Item Ships From | New Jersey |
