Product Description

MATERIALS: Stainless Steel, Type 300 Series, nickel-bearing, 1/4" clear tempered sheet glass.
GAUGES: Sides, backs, tops, bottoms, shelf-18 gauge. Doors and drawers-20 gauge. Legs-12 gauge.
CONSTRUCTION:

  • Cabinet consists of upper and lower compartments, which separated by a stainless steel work surface, with seamless welded faces and doubled front edges.
  • Upper Compartment:
    • Glass paneled doors of double shell design formed to hold a rubber gasketed glass panel.
    • Right hand door equipped with locking knob and three way latching, left hand door with dummy knob and roller catch, operating on semi-concealed stainless steel hinges.
    • Three glass shelves, with all edges ground smooth and polished, adjusts on 1/2" increments on full height stripping welded to back and front of cabinet.
    • An independently locked narcotic cabinet, 13 1/4" x 5" x 7 3/4" with double walled door, is welded to the bottom, back and side of compartment.
  • Lower Compartment:
    • One double pan door with bar pull hung on semi-concealed stainless steel hinges.
    • Three half width, full depth, 7" deep drawers, with channeled edges and horizontally coved intersections, welded to drawer heads fitted with die-cast aluminum bar pulls.
    • Slides with integral stops and ball bearing rollers are welded to drawer sides, with mating body slides secured to the cabinet interior.
    • Cupboard equipped with one removable stainless steel shelf.
  • Upper and lower sections are joined together by four supports, two each at front and rear edges of the upper cabinet. Front supports are 1 1/4" square stainless steel tubing and back supports concealed by the backsplash of the stainless steel base cabinet top.
  • Cabinet is mounted on four stainless steel glide equipped offset legs, welded to bottom corners.

DIMENSIONS:

  • Overall: 36" W x 76.5" H x 16" D
  • Upper Compartment: 36" W x 42.5" H x 8" D
  • Lower Compartment: 36" W x 34" H x 16" D

WELDING: Welding is accomplished by heli-arc method. All exposed welds ground smooth.
FINISH: Exposed surfaces are free from pit marks, weld seams and scale, and polished to a satin finish.
OPTIONS: Casters, Stainless steel shelves for upper compartment, Sloping top.

Please Note: This item ships motor freight carrier. During the checkout process you will be required to indicate whether your facility requires liftgate or inside delivery services. (These services are described on our shipping information page.) In the order comments please include a name & phone number for the delivery point of contact. Please also include receiving hours and any other delivery requirements or instructions. If additional services necessitate an additional fee, you will be contacted by Customer Service. If you have questions about the motor freight delivery process please contact Customer Service prior to placing your order.

Specifications

Specifications
Manufacturer Blickman
Country of Manufacture United States
Item Ships From New Jersey
GSA Contract Number V797D-40002

Literature 1

pdf
(Size: 24.7 KB)

Instructions

Warranty:

Blickman warrants to the original purchaser that its Proprietary Products will be free from defects in workmanship or materials under normal use and service for the life of the product, so long as owned by the original purchaser, according to the limitations set forth below. Defective products shall be repaired or replaced at Blickman's option at no cost to the original purchaser provided: 1. The customer must obtain a written return authorization supplied by Universal Medical 2. The customer must pre-pay freight charges to and from Blickman and must ship merchandise in the original packaging.

This warranty does not apply to products, which have been subject to abuse, misuse, accident, modification, alteration, tampering, negligence, lack of routine maintenance or misapplication; or products that have been repaired by other than Blickman or its authorized representatives. This warranty does not apply to glass, fabrics, vinyl, seat coverings, cushions, padding or their stitching, gluing or installation. Component parts not manufactured by Blickman, such as casters, caster inserts, any components made from rubber or plastic, circuit boards, fan heaters, plumbing parts, electrical switches and components are also excluded. For these component parts, Blickman will pass on the original manufacturer's warranty to Blickman equipment original purchasers. Please consult factory for questions regarding the warranties of these component parts. This warranty does not apply to custom fabricated products. Consult factory.

Unless expressly set fortn in this warranty, there are no other warranties, whether express or implied, of fitness and/or merchantability or any other warranty implied by custom, usage or course of dealing. Liability of Blickman under this warranty is limited to the repair and / or replacement of any products. Blickman specifically excludes and disclaims any responsibility for any incidental or consequential damages claimed to have arisen from any defect in workmanship or materials. No representative has any authority to change or enlarge the above warranty or Blickman liability. This document supersedes all previous warranty provisions.

Returns

This item is made to order and as such is NOT able to be returned.

Reviews

Ask a Question (3)

Customer Questions
When was this product first introduced - maybe the 1950's?

This item was introduced around 1947.

What is the measurements of the glass shelves in the cabinet and if these shelf can be replaced with metal?

The glass shelves for the upper cabinet measure 6 3/8" deep X 35 3/8" wide. Metal shelves can be provided as a special request. The metal shelves would be the same measurements as the glass shelves.

What is the total weight of the 36" W Kennedy cabinet?

The total weight of this cabinet is 290 lbs
