Compact and packed full of high-end design features making it a versatile shaker for a vast range of protocols.
Orbital shaker body is made from durable ABS to resist most commonly used chemicals, and is easy to clean
No-stop electronic motor feedback, enables the unit to instantly adjust to weight load changes and unbalanced loads for truly reproducible results
A high weight loading of 4.5 kg (10 lbs.), with an overload protection shut-off
Universal hi-lo platform and bungee cords allows you to create your own holding matrix for vessels of all shapes and sizes
Suitable for use in incubators and cold rooms within the stated temperature range
Time and speed can be separately set
Back-lit display is easy to read
Soft-start and shut down feature at higher speeds reduces spill instances from full vessels
Very low start speed for sensitive sample agitation, with a high top end and good stability for more vigorous applications
Long-life maintenance free motor and drive
Powered by 12V DC, includes double insulated worldwide power adapter, 110V to 240V, supplied with 4 different plugs for power adapter
Digital Orbital Shaker is for Indoor Use ONLY
Speed Range
20 to 300 rpm 1 rpm increments
Orbit Diameter
19.0 mm (0.75")
Timer Range
0 to 74 hours and 59 minutes 1 second increments or continuous
Maximum Load
4.5 kg (10 lbs.)
Power
110 to 240 VAC, 50/60 Hz with 4 interchangeable plug adapters
Ambient Conditions
2° to 40°C (36° to 104°F); 20 to 80% RH, non-condensing
Platform Interior Dimensions
11" W x 11" D (27.9 cm W x 27.9 cm D)
Overall Dimensions (LxWxH)
12.36" x 12.20 x 7.75" (31 cm x 31.4 cm x 19.7 cm)
Warranty
3-year
Certified Unit:
•CE certified •Conforms to: ANSI/UL Std. 61010-1, Certified to: CAN/CSA Std. C22 No. 61010-1, CENELEC EN 61010-1 •RoHS Conforms to EU directive 2002/95/EC (RoHS) and EU directive 2003/11/EC
Package Includes
•Digital Orbital Shaker •Universal hi-lo platform with soft rubber edge bumpers •Skid-free rubber platform mat •8 bungee cord set •Universal power adapter 110–240v 50/60 Hz, with 4 interchangeable plug types
Specifications
Specifications
Manufacturer
Heathrow Scientific
Actual Product Weight
27.92 lbs
Overall Height
7.75"
Overall Width
12.20"
Overall Length
12.36"
Country of Manufacture
China
Item Ships From
Illinois
