Solace In-Floor Dialysis Scale with Hand Rail
Product Description
DETECTO'S Solace In-Floor Dialysis Scales with Handrails are flush-mounted platform scales that feature stainless steel decks, and include a pit frame, trim ring, and interface cable to the included multi-color, touchscreen LCD indicator, and printer. The flush surface eliminates tripping hazards and hallway accessibility issues. These in-floor scales easily accommodate patients with walkers, canes, wheelchairs, or seated in dialysis chairs.
- Wraparound tubular handrail with padded handgrip for patient stability
- 1000 lb / 450 kg capacity
- Flush-Mounted with floor for easy accessibility
- Stainless steel, anti-corrosion weighing platform
- Platform sizes: 3 x 3 ft, 4 x 3 ft, 4 x 4 ft, and 6 x 4 ft (accommodates stretchers)
- Wall-Mounted multi-color touchscreen indicator
- Built-in thermal printer makes it easy to print out a weight record for patient record-keeping
- Large 0.9" high LCD weight digits
- Push button or manual entry of tare weights for wheelchairs and stretchers
- Automatically locks on weight temporarily for a few seconds in order to easily view and record measurement
- Menu button provides quick access to user-friendly menu settings for scale customization
- Standard 110V AC power 110V - 240V AC universal switching power supply
- Solace In-Floor Dialysis Scale without Handrail models are available
- 2-year warranty
| Model |
ID-3636SH-855RMP |
ID-4836SH-855RMP | ID-4848SH-855RMP | ID-7248SH-855RMP |
| Includes |
Solace In-Floor Scales with Handrails come with model 855RMP digital weight indicator/ printer combo, pit frame, scale, stainless steel deck, and trim ring |
|||
| Handrail | Wraparound tubular handrail with padded handgrip for patient stability | |||
| Capacity | 1000 lb x 0.2 lb / 450 kg x 0.1 kg | |||
| Platform Construction | Anti-corrosion stainless steel | |||
| Platform Size | 36" x 36" | 48" x 36" | 48" x 48" | 72" x 48" |
| Indicator/Printer |
Recessed-mount, touchscreen model 855 indicator, Thermal ticket printer combo with stainless steel cover plate |
|||
| Display Type | 3.2 in (diagonal) full color TFT display 320 x 240 resolution | |||
| Keypad |
Mechanical switch type with 7 buttons: Power, Zero, Lock/Release, ID, Cycle Display Mode, Menu, Print |
|||
| Number of Character |
Weight: 5 digit, 0.9 in (23 mm) high Height: 4 digit, 0.35 in (9 mm) high BMI: 3 digit, 0.35 in (9 mm) high |
|||
| Operating Environment |
Operating Temperature Range: 14 to 104°F (-10 to +40°C) Humidity: 0 to 90% non-condensing |
|||
| Digital Filtering | StableSENSE® Adjustable Filtering | |||
| Power | 110 to 240 VAC universal switching power supply | |||
| Approvals | OIML | |||
| Country of Origin | USA | |||
| Shipping Weight | 265 lb | 321 lb | 398 lb | 522 lb |
| UPC Code | 809161203806 | 809161204001 | 809161204209 | 809161204407 |
Specifications
| Manufacturer | Detecto Scales |
|---|---|
| Latex Free | Yes |
| Weight Capacity | 1000 lb / 450 kg |
| Country of Manufacture | United States |
| Item Ships From | Missouri |
Literature
Instructions
Warranty:
Detecto Scale warrants its equipment to be free from defects in material and workmanship as follows:
- Detecto warrants to the original purchaser only that it will repair or replace any part of equipment which is defective in material or workmanship for a period of two (2) years from date of shipment. Detecto shall be the sole judge of what constitutes a defect.
- During the first ninety (90) days Detecto may choose to replace the product at no charge to the buyer upon inspection of the returned item.
- After the first ninety (90) days, upon inspection of the returned item, Detecto will repair or replace it with a remanufactured product. The customer is responsible for paying for the freight both ways.
This warranty does not apply to peripheral equipment not manufactured by Detecto; this equipment will be covered by certain manufacturer’s warranty only.
This warranty does not include replacement of expendable or consumable parts. This does not apply to any item which has deteriorated or damaged due to wear, accident, misuse, abuse, improper line voltage, overloading, theft, lightning, fire, water or acts of God, or due to extended storage or exposure while in purchaser’s possession. This warranty does not apply to maintenance service. Purchased parts will have a ninety (90) day repair or replacement warranty only.
Conditions Which Void Limited Warranty
This warranty shall not apply to equipment which:
A.) Has been tampered with, defaced, mishandled or has had repairs and modifications not authorized by Detecto.
B.) Has had serial number altered, defaced, or removed.
C.) Has not been properly grounded according to Detecto’s recommended procedure.
