Product Description

The 5400 Series universal transport stretcher is versatile, yet economical. It's the right stretcher for ED, OR, PACU, or any department where cost, efficiency and quality are required.


  • Overall Length: 83" - Overall Width: 33.5"
  • Height Range: 23" - 32.75"
  • Fowler Backrest: 0-90 degrees
  • Trendelenburg: +12 degrees -Reverse Trendelenburg: -7 degrees
  • Patient Surface: 77" x 31"
  • Side Rails: 15" x 63 5/8"
  • Casters: 8"
  • Weight Capacity: 500 lbs
  • Warranty: 1 year parts and labor
  • Product Actual Weight: 385 lbs, Product Shipping Weight: 425 lbs

Standard Features:

  • True Direction Steering (TDS): For improved stretcher control engage the True Direction Steering system. The steer caster located at the patient's right foot end of the stretcher will lock once the steering pedal is applied.
  • Side rails: Full length, single release. Easy to wipe clean and disinfect, tuck-away side rails allows for easier patient transfer by creating a zero transfer gap. Rails feature a release latch centrally located on either side of the litter top under the patient surface.
  • Pneumatic Assist Fowler: Provides additional assistance for the safe and easy raising and lowering of the patient. Pneumatic assist fowler 400 N (90lb.) force.
  • Positive/negative Trendelenburg single pneumatic assist cylinder.
  • Hydraulic Height Adjustment Foot Pedals: Hydraulic Foot Pedals are located on each side of the stretcher within the patient care zone. Color-coded pedals and function graphics are quickly and easily understood.
  • Trendelenburg: A single pneumatic cylinder assists in placing the litter top in Trendelenburg/reverse Trendelenburg position.
  • Center Column Support: Sturdy steel column with single hydraulic lift cylinder design uses sixteen precision ball-bearing to smoothly raise and lower the patient.
  • Patient Lifts: The 5400 Series Stretcher has 5 7/8" H of clearance between floor and cowling to easily accommodate and utilize patient lifts.
  • Brake & Steer activated foot pedals
  • Four corner IV pole receptacles
  • Four restraint strap positions
  • Full gray PVC perimeter bumper
  • Latex-free
  • Mattress is not included and must be purchased separately

Please Note:

  • Photo may be shown with optional accessories that are not included.
  • This item ships motor freight carrier. During the checkout process you will be required to indicate whether your facility requires liftgate or inside delivery services. (These services are described on our shipping information page.) In the order comments please include a name & phone number for the delivery point of contact. Please also include receiving hours and any other delivery requirements or instructions. If additional services necessitate an additional fee, you will be contacted by Customer Service. If you have questions about the motor freight delivery process please contact Customer Service prior to placing your order.
  • We are unable to sell this item to Premier GPO members.

About this Brand


Manufacturer Pedigo
Latex Free Yes
Actual Product Weight 385 lbs
Weight Capacity 500 lbs
Country of Manufacture United States
Item Ships From Washington
GSA Contract Number V797D-40002


Request for Return must be submitted to Customer Service within 14 days of product receipt. All returns must be in unused, resalable condition in the original packaging. A restocking fee will be deducted at the discretion of the manufacturer. All shipping charges remain payable by the purchaser.
