Huntleigh Healthcare Dopplex® DMX Doppler with Single-Use Intraoperative 8 MHz Probe, PA8XS Adaptor, and IV Pole Clamp

The Huntleigh Healthcare Dopplex® DMX Doppler with Single-Use Intraoperative 8 MHz Probe, PA8XS Adaptor, and IV Pole Clamp is a set of products with a combination of the Huntleigh Healthcare Dopplex® DMX Doppler, Waveform Display and Sterilized, Single-Use Intraoperative 8 MHz Probe with PA8XS Adaptor and IV Pole Clamp, intended for vascular use.

Features:

• DMX single-use IOP system that includes a DMX Doppler with a high-resolution color display of the vascular waveform, PA8XS probe adaptor, Box of 10 sterile, single-use 8 MHz probes, and IV pole clamp
• High-resolution color display - Instantly visualise waveforms for pictorial evidence, displayed in high-definition, with a wide viewing angle
• Bi-directional waveform display
• A dedicated venous mode allows any reflux to be clearly visualized by the flow pattern above the baseline
• Audio Output - Flow-separated stereo headphone output
• USB port for communication with our software
• Convenient charging via USB port
• Data Storage on Micro SD Card - Stores timestamped waveforms and sounds for review or training and transfers to optional Dopplex Vascular Reporter software package for reporting and archiving
• Digital Sound Processing - Reduces background hiss and loud crackle when gel is applied
• Probe Parking - Protection when probe not in use
• High Sensitivity Interchangeable Probes - All probes have been calibrated and fine-tuned for optimum use
• Integrated belt/pocket clip for convenient carrying and storage
• Assesses Peripheral Arterial Disease (PAD), measures Ankle-Brachial Index (ABI) and Toe Brachial Index (TBI) to assess the Diabetic and lymphatic foot with the optional APPG probe
• For use in conjunction with the *Dopplex Vascular Reporter, software that facilitates a more detailed examination of Doppler waveforms stored on the DMX Doppler on a PC, including as a colour spectrum. It can be applied to various studies, and it also features an integrated PDF generator
• Detects residual stenosis in carotid surgery, blood flow following vessel repair, and AV ducts or shunts
• Checking flow in bypass grafts
• Locating renal and hepatic arteries during transplants and small arteries on skin flaps

Comes Standard With:

• (1) Dopplex® DMX Digital Doppler
• (1) PA8XS Intraoperative Probe Adapter for DMX/DMXR Doppler
• (10) Sterilized Single-Use Intraoperative 8 MHz Probe
• (1) IV Pole Clamp

Technical Specifications:

• Noise Reduction: Digital Dynamic Noise Reduction (DDNR)
• Removable Micro SD Card Storage: Yes
• Scroll Memory: 20 seconds
• Timebase: 3, 6, and 12 seconds
• Compatible with Interchangeable XS Probes: Yes
• Integrated Loudspeaker: Yes
• Gain Control: Auto
• Dopplex Software Compatible: VR
• USB Capability: Micro
• Battery Type: (2) AA Alkaline Batteries
• Battery Life (no. of 1-min exams): Over 700
• Warranty: 3 years on Doppler, 1 year on probes and accessories, 90 days on intraoperative probe and cable

*Dopplex vascular reporter software is sold separately.
