Hoshizaki Healthcare Series Single-Section Warming Cabinet with 4 Wire Shelves, Stainless Steel Door - 22.70 Cubic Feet
Usually Ships in 5-7 Business Days
In stock
Product Description
The Hoshizaki Healthcare Series Single-Section Warming Cabinet with 4 Wire Shelves, Stainless Steel Door - 22.70 Cubic Feet offers reliable warming with three preset temperatures, durable stainless steel construction, and UL 61010 certification, ensuring long-lasting performance and electrical safety, and making it a dependable solution for healthcare settings.
Features:
- Three preset temperatures for convenience:
- 130°F for Linens and Blankets
- 110°F for Irrigation Fluids
- 98°F for Blood Products
- Maximum interior storage capacity with the smallest external footprint
- Interior top-mounted heating element with a fan to circulate heat through the cabinet for optimal airflow
- Foamed-in ceramic heat shield next to the heating element maintains the cabinet's structural integrity
- Stainless steel interior and exterior front, sides, and top provide resistance to rust, and are easy to clean
- Solid-state digital controller with visual high/low temperature alarm, high/low voltage alarms
- The LED display shows the cabinet temperature and is adjustable to Fahrenheit or Celsius
- High/low temperatures and door open audible alarms
- Built-in high-temp safety switch and built-in overload protection
- Energy-efficient 6000 K interior LED lighting
- 4 Epoxy-coated wire shelves are adjustable in 1″ increments on stainless steel supports
- The cabinet has a unique ducted air flow system
- Cabinet walls and door are insulated with 2-3/8” of environmentally friendly, CFC-free, foamed-in-place polyurethane
- ADA-compliant, full door length, extruded aluminum flush mount handle
- Lockable stainless steel door stays open at 90° for easy product loading/unloading
- The door is spring-assisted and is self-closing at 75°
- Exclusive stepped door design to protect the recessed door gasket
- Snap-in magnetic door gaskets are easily removed for cleaning
- Field-reversible door
- Sturdy 8-gauge stainless steel hinge plate with welded hinge pin
- Standard with (4) 3.63” heavy-duty, easy-to-roll stem casters (two with brakes)
- 10 ft. cord and plug
- UL 61010 certified for electrical and fire protection safety requirements
Technical Specifications:
- Capacity: 22.70 Cubic Feet
- Sections: Single-Section
- Adjustable Shelves: 4 Epoxy-Coated Wire Shelves
- Door: Stainless Steel Door
- Material:
- Exterior:
- Front, Sides, and Top: Stainless Steel
- Back and Bottom: Coated Steel
- Interior: Stainless Steel
- Pilasters: Stainless Steel
- Cabinet Walls and Door Insulation: 2-3/8” Polyurethane
- Casters: 3.63” Polyolefin
- Exterior:
- Electrical Voltage: 115 V / 60 Hz / Single-Phase
- Max Fuse/HACR Breaker: 15 A
- Electrical Connection: NEMA 5-15P
- Voltage Range: 104-126 V
- Ambient Temperature Range: 45°F to 100°F
- Control Setpoint Range: 90°F to 150°F
- Amperage: 10 A
- Cord and Plug Length: 10' L
- Shelf Dimensions: 21.25" W x 26" D
- Door Opening Dimensions: 21.75" W x 59.25" H
- Depth with Door Open at 90º: 59.25” D
- Overall Dimensions: 27.50" W x 33.50" D x 72" H
Specifications
| Manufacturer | Hoshizaki America |
|---|---|
| Latex Free | Yes |
| Overall Height | 72" |
| Overall Width | 27.50" |
| Overall Depth | 33.50" |
| Temperature Range | 90°F to 150°F |
| Country of Manufacture | United States |
| Item Ships From | California |
| Door Style | Stainless Steel |
Literature
Instructions
Warranty: Hoshizaki Steelheart® and HX Series Refrigerators, Freezers, Heated Holding Cabinets, and Heated Warming Cabinets are warranted to the original owner/user to be free from defects in materials and workmanship under normal use and proper maintenance. Products are covered by a 7-year parts and labor warranty, including the compressor. Solid-door upright models also include a limited lifetime warranty on doors and hinges after the initial 7-year warranty period, excluding labor charges. Warranty registration must be completed within 30 days of installation. Warranty does not cover wear items, improper installation, misuse, neglect, unauthorized modifications, electrical issues, or lack of required maintenance.
