Edan SE-301 3-Channel Handheld ECG with 5" Touch Screen

The Edan SE-301 3-Channel Handheld ECG with 5" Touch Screen is an advanced and compact machine that is exceptionally designed with state-of-the-art technologies to provide intuitive operation with optimized performance, and accurate and consistent results.

Features:

• Ultra-Compact Design:
  • Lightweight
  • Built-In Printer
  • High-Resolution Color Touch Screen
  • Built-In Rechargeable Li-ion Battery
  • Anti-Noise Technology
  • Full-Touch Operation
  • One-Button Operation
• Superior Technology:
  • 12-Lead Acquisition and Display
  • Linear/2D Barcode Scanner Support
  • Signal Quality Identification
  • External Printer via USB Port Support
• Powerful External Device Support: (2) USB ports and (1) MicroSD card slot, which extends its capability by supporting various external devices such as a barcode scanner, external printer, USB memory drive, or a microSD card
• Bi-Directional Communication with Data Management System: Via the LAN or built-in WiFi (SE-301-WIFI), this device can receive orders from the SE-1515 Data Management System and transmit the ECG reports back for further analysis, editing, saving, or printing
• CMRR: A high common mode rejection ratio up to 140 dB restrains signal noise to the greatest extent, giving excellent quality traces
• Bandwidth: A wide bandwidth from 0.01 to 300 Hz guarantees the accuracy of the ECG signal, as well as the interpretation, especially for pediatric patients
• Sampling Rate: The leading sampling rate of up to 16,000 Hz aims at capturing all the details to generate precise results
• Signal Quality Detection: By showing different colors to indicate normal, poor, or missing signals, this function helps to identify signal quality even at a glance
• Reliable SEMIP ECG Algorithm: Offers an accurate and reliable reference to maximize clinicians' confidence in making diagnosis
• Available Options:
  • SE-301: Without WiFi
  • SE-301-WIFI: With WiFi
• Multiple Ports:
  • USB Socket
  • Net Port
  • Power Port
  • Grounding Port
  • SD Card Slot
• Comes Standard With:
  • (1) ECG Cable with 4 mm Banana Connector
  • (1) Adult Resting Tab Electrodes
  • (1) 10-Lead Universal Clips
  • (1) Recording Paper (80 mm x 20 m Roll)
  • (1) Paper Roll
  • (1) US Standard Power Cord
  • (1) Power Adapter (16V)
  • (1) Rechargeable Lithium-Ion Battery (2500 mAh)

Technical Specifications:

• Display: 5", 800×480 Multicolor LCD Touch Screen
• Power Supply:
  • Main Supply:
    • Operating Voltage: 100V - 240V
    • Operating Frequency: 50 Hz/ 60 Hz
    • Power Adapter Output Voltage: 19V, 2 A
  • Internal Lithium-Ion Battery Pack:
    • Rated Voltage: 14.8V
    • Rated Capacity: 2500 mAh (5 Hours Continuous Printing, 500 ECG Reports)
    • Necessary Charge Time: ≤3.5 Hours
• Recording:
  • Recorder: Thermal Dot-Matrix Recorder
  • Printing Density:
    • 8 Dots per mm / 200 Dots per inch (Amplitude Axes)
    • 40 Dots per mm / 1000 Dots per inch (Time Axes, @ 25 mm/s)
  • Recorder Paper:
    • Folded Thermal Paper: 80 mm x 70 mm x 200 pages
    • Rolled Thermal Paper: 80 mm x 20 m
  • Paper Speed: 5 mm/s, 6.25 mm/s, 10 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s
  • External Printer: HP 1010/1510/2010/1050/2000, HP M401/2015/2035/1525, HP 1020/1020PLUS/1106, HP 1505
• HR Recognition:
  • HR Range: 30 BPM ~ 300 BPM
  • Accuracy: ±1 BPM
• ECG Unit:
  • Leads: 12 Standard Leads
  • Acquisition Mode: Simultaneously 12 Leads
  • A/D Converter: 24 Bits
  • Resolution: 0.1575 μV/LSB
  • Time Constant: ≥ 3.2 s
  • Frequency Response: 0.01 Hz ~ 300 Hz (-3 dB)
  • Gain: 2.5, 5, 10, 20, 10/5 mm/mV, AGC
  • Input Impedance: ≥ 50 MΩ (10 Hz)
  • Input Circuit Current: ≤ 0.01 μA
  • Input Voltage Range: ≤ ±5 mVpp
  • Calibration Voltage: 1 mV±2%
  • CMRR: ≥ 140dB
  • Sampling Frequency: 16000 Hz
• Pacemaker:
  • Amplitude: ±2 to ±700 mV
  • Width: 0.1 to 2.0 ms
  • Sampling Frequency: 16000/Sec/Channel
• Filter:
  • AC Filter: On/Off (50/60 Hz)
  • DFT Filter: 0.01Hz, 0.05Hz, 0.32Hz, or 0.67Hz
  • EMG Filter: Off/ 25 Hz/ 35 Hz/ 45 Hz
  • LOWPASS Filter: 300 Hz/ 270 Hz/ 150 Hz/ 100 Hz/ 75 Hz
• Data Transmission:
  • Report Format: PDF, XML, DICOM, FDA-SCP
  • Data Transmission: Wi-Fi, Ethernet, RS232
  • Data Management System:
    • SE-1515 Data Management System
    • Bi-Directional Communication
  • HIS Connection: DICOM Worklist/ DICOM Storage/ HL7
• Wi-Fi (SE-301-WIFI):
  • Transmitting Frequency: 2.4 GHz
  • Frequency Band: 2.400-2.500 GHz (2.4 GHz ISM Band)
  • Modulation Type:
    • OFDM with BPSK, QPSK, 16-QAM, and 64-QAM
    • 802.11b with CCK and DSSS
  • Transmitting Power:
    • 17 dBm for 802.11b DSSS
    • 17 dBm for 802.11b CCK
    • 15 dBm for 802.11g/n OFDM
• Safety Specifications:
  • Anti-Electric-Shock Type: Class І with Internal Power Supply
  • Anti-Electric-Shock Degree: CF Type with Defibrillation-Proof
  • Patient Leakage Current:
    • NC < 10 μA (AC) / < 10 μA (DC)
    • SFC < 50 μA (AC) / < 50 μA (DC)
  • Patient Auxiliary Current:
    • NC < 10 μA (AC) / < 10 μA (DC)
    • SFC < 50 μA (AC) / < 50 μA (DC)
• Working Environment Specifications:
  • Temperature: +5ºC ~ +40ºC
  • Relative Humidity: 15% ~ 95% Non-Condensing
  • Atmospheric Pressure: 86 kPa ~ 106 kPa
• Overall Dimensions: 8.82" L x 5.63" W x 2.13" H
• Actual Product Weight: 2.20 lbs (Excluding Recorder Paper and Battery)
• Warranty: 2 Years
