Edan SD3 Ultrasonic Pocket Vascular Doppler, Non-Display with Vascular Probe

The Edan SD3 Ultrasonic Pocket Vascular Doppler, Non-Display with Vascular Probe is a hand-held device used for the assessment of peripheral vascular disease. Its portability makes it ideal for the effective assessment of both venous and arterial disease.

Features:

• Plug-and-play and waterproof interchangeable probes
• Compact design with easy one-hand operation
• Designed for the auscultation of fetal sounds
• Built-in speaker with adjustable volume
• Real-time monitoring for daily use
• Compatible with AA batteries
• Automatic power-off for battery power saving. It will turn off when the doppler receives no signal or operation for 1 minute
• The SD3 Vascular is compatible with the following waterproof vascular probe choices:
  • Vascular Probes - Used for blood flow detection and vascular diagnosis
    • 02-01-210875 - 4 MHz
    • 02-01-210876 - 5 MHz
    • 02-01-210877 - 8 MHz
• It comes standard with:
  • Carry case
  • (1) Waterproof, interchangeable probe
• Available in different probe combinations

Note: The SD3 Ultrasonic Pocket Vascular Doppler does not have a display screen.

Technical Specifications:

• Display: 0.96" OLED Double Color Screen
• Audio Output: 2 W
• Audio Sampling Frequency: 4 kHz
• Recording Length: 240 seconds
• Coupling Gel:
  • pH: 5.5 - 8.0
  • Acoustic Impedance: 1.5 x 10⁶Pa.s/m - 1.7 x 10⁶Pa.s/m (35°C/95°F)
• Temperature:
  • Working: 5°C - 40°C
  • Transport and Storage: -20°C - 55°C
• Relative Humidity:
  • Working: 25% - 80% (Non-condensing)
  • Transport and Storage: 25% - 93% (Non-condensing)
• Atmospheric Pressure:
  • Working: 86 kPa - 106 kPa
  • Transport and Storage: 70 kPa - 106 kPa
• Power Supply:
  • 3 AA alkaline battery LR6: Normal working time ≥ 10 hours
  • 3 AA rechargeable HI-MH battery R6: Normal working time ≥ 10 hours, 5 hour charge time
• Vascular

  • Operating Mode: CW
  • Working Frequency: (4±10%) MHz/(5±10%) MHz/(8±10%) MHz
  • Nominal Frequency: 4 MHz/5 MHz/8 MHz
  • Ultrasound Output (4 MHz/5 MHz/8 MHz Probes):

    • p- < 1 MPa
    • Iob < 25 mW/cm²
    • Ispta < 100 mW/cm²
  • Effective Radiating Area of Transducer:
    • 4 MHz/ 5 MHz: (32±15%)mm²
    • 8 MHz: (14±15%)mm²
• Warranty: 1 Year
• Overall Dimensions: 6.61" D x 1.22" W x 2.64" H
