Burton Medical APEX LED Surgical Light AP160 Ceiling Mounted with Short Down Tube
Product Description
The Burton Medical APEX LED Surgical Light AP160 Ceiling Mounted with Short Down Tube is compact and lightweight, revolutionizing the surgical experience.
Features:
- A single light head surgical light with a 12" short down tube
- Customizable brightness with 5 dimming levels
- Effortless, light movement and visible control
- A combination of tri-lobe, state-of-the-art LED technology, and light head optics provides a superior shadow reduction
- Seamless construction and reduced surface area enhance cleaning efficiency and ease of disinfection
- Non-drifting arm, maintained by Burton’s reliable positioning system
- Spring-balanced suspension arm and a minimalist, lightweight light head that offers complete freedom of movement
- Out-of-the-box ease of installation with a plug-and-play assembly of lightweight suspension arm and light head
- Available in a dual-arm configuration to support both a light head and a monitor mount
Technical Specification:
- Product Type: Surgical Light
- Maximum Illuminance: 160,000 Lux
- 5 Dimming Levels: 100,000/115,000/130,000/140,000/160,000 Lux
- Depth of Illumination: 47"
- Light Field Diameter (D10): > .53
- D50 / D10R9: > 97
- Color Rendering Index (CRI): > 97
- High CRI (Color Rendering Index): > 97
- LED Service Life: > 50,000 Hours
- Power Consumption: 80 Watts
- Color temperature: 4100 K
- Number of LEDs: 12 Modules (6 LEDs per Module)
- Endo Mode: Yes
- Standby Power Indicator: Yes
- IP Rating: IP42
- Certifications: FDA Registered, ISO 13485, UL/IEC 60601-1, IEC 60601-1-6, IEC 60601-2-41, IEC 60601-1-2, IEC 62471, CAN/CSA C22.2 No. 6-01 M90, UL, CE Certifications
- Light Head Diameter: 22"
- Down Tube Length: 12"
- Light Head Weight: 13 lbs
| SKU | Arm Length | Actual Product Weight |
| AP160A01 | 29.13" | 137 lbs |
| AP160B01 | 35" | 142 lbs |
| AP160C01 | 41" | 142 lbs |
| AP160A07 | 29.13" and 35" | 201 lbs |
| AP160B07 | 35" and 41" | 210 lbs |
About this Brand
Since 1928, Burton has been designing and manufacturing high-quality examination, procedure, and surgical lighting. The company is known for superior products that provide long-lasting solutions to complex lighting issues facing physicians, surgeons, and veterinarians. Accurate color visibility, energy efficiency, long lamp life, and flexible light placement are hallmarks of Burton medical lighting products.
Specifications
| Manufacturer | Burton Medical |
|---|---|
| Latex Free | Yes |
| Country of Manufacture | United States |
| Item Ships From | Illinois |
