Accuris SmartReaderâ„¢ Microplate Multimode Reader
Usually Ships in 5-7 Business Days
In stock
You May Also Need
Checked products are added to the cart with this item.
Product Description
The SmartReaderâ„¢ Microplate Multimode Reader is designed to meet the growing needs of advanced life science labs. Equipped with a full suite of high-performance optical systems.
Features:
- All-in-one solution for absorbance, fluorescence, and luminescence applications
- Monochromator-based system for UV through visible absorbance
- Allows for automatic dynamic range selection, which allows for the gain of the photomultiplier tube to accurately capture and normalize the signal intensity of samples
- Built-in plate shaker with linear, orbital, and double-orbital shaking modes, and an incubator that can perform top heating from ambient + 4°C – 45°C
- The program and operation are managed from the instrument’s large color touch screen, and no external computer or software is required
- Filter module system for fluorescence assays
- Advanced PMT detector for luminescence assays
- Three filter modules are included to provide the most common excitation and emission wavelengths needed for fluorescence assays
- Capable of luminescent detection, and can process both flash and glow assays
- Advanced PMT (photo multiplier tube) enhances the sensitivity of weak signals, prevents over-saturation of strong signals, and provides an ideal detection range for all common luminescence applications
Technical Specification:
| Absorbance | |
| Light Source: | High Energy Xenon Flash Lamp |
| Detector: | Photodiode |
| Wavelength Accuracy: | 2 nm |
| Wavelength Repeatibility: | 0.2 nm |
| Bandwidth (FWHM): | > 2.5 nm |
| Wavelength Range: | 200 - 1000 nm, 1 nm steps |
| Absorbance Range: | 0.0 - 4.0 OD |
| Resolution: | 0.0001 OD |
| Accuracy: | 96-precision mode: ± (1.0 %+0.003Abs) @ (0.0-2.0Abs] ± 2.0 % @ (2.0-3.0Abs] |
| Repeatibility: | CV < 1.0 % or SD< 0.003 Fast (0.0-3.0Abs] CV < 0.5 % or SD< 0.003 Accurate (0.0-3.0Abs] |
| Stray Light: | 0.1 % @ 220 nm |
| Linearity: | R2 > 0.999 @ [0.0-3.0Abs] |
| Measurement Speed: | < 15 seconds |
| Fluorescence | |
| Reading Mode: | Top Reading |
| Excitation Light Source: | High Energy Xenon Flash Lamp |
| Detector: | Photo Multiplier Tube (PMT) |
| Detection Limit: | ≤ 1 pM |
| Wavelength Range: | EX: 200 - 1000 nm; EM: 270 - 850 nm |
| Included Filter Cartridges: | (EX / EM): 470 / 525nm; 523 / 564nm;Â 624 / 692nm |
| Linear Dynamic Range: | 6 logs |
| Luminescence | |
| Detector: | Photo Multiplier Tube (PMT) |
| Detection Limit: | 15 amol / well |
| Linear Dynamic Range: | 6 logs |
| Crosstalk: | ≤ 0.005% |
| General Specifications | |
| Measurement Technologies | Absorbance, Fluorescence, Luminescence |
| Plate Formats | 6- to 384-well plates |
| Shaking |
|
| Incubation Range | RT +4 °C to 45 °C |
| Temperature Uniformity | ± 0.5 °C @ 37 °C |
| Display | 10" touchscreen |
| Communication Ports: |
|
| Power Input: | AC 100V, 50 to 60 Hz |
| Warranty: | 2 years |
| Overall Dimensions (L x W x H): | 15.2" x 21.7" x 16.5" |
| Actual Product Weight | 73 lbs |
Please Note: The well plate in the image is sold separately.
Specifications
| Manufacturer | Benchmark Scientific |
|---|---|
| Actual Product Weight | 73 lbs |
| Country of Manufacture | China |
| Display Type | Full Color LCD Touchscreen |
| Light Source | High Energy Xenon Flash Lamp |
| Overall Height | 16.5" |
| Overall Length | 15.2" |
| Overall Width | 21.7" |
| Power Supply | AC 100V, 50 to 60 Hz |
| Wavelength | 200 - 1000 nm, 1 nm steps |
| Item Ships From | New Jersey |
