Product Description

This Deluxe Combination Warmer features 4 digit LED display, window doors, control lock programming and auto time programming. It is designed to safely store and warm either irrigation or injection fluids and blankets.

Features:

  • Top compartment for blankets, lower compartment for fluids
  • Slim dual-cabinet design with 20 gauge stainless steel exterior casing and doors
  • Window doors and interior lighting provides at-a-glance inventory from across the room
  • Individual electronic controls for each compartment
  • The cabinet is warmed using Electro-thermal Radiant Heat Technology to assure accurate set-point temperatures
  • The electrothermal cable is positioned in the floor and two sides of the warming cabinet, providing even heating of the interior chamber
  • The blanket warming chamber contains an epoxy-coated blanket support assembly and one (1) shelf
  • The fluid warming chamber is equipped with three (3) epoxy-coated metal baskets to accommodate fluids packaged in bags or bottles, mounted on basket rail supports. Each basket has a maximum capacity of 24 liters; Total capacity is 72 liters.
  • The cabinet is furnished with a full perimeter rubber bumper assembly for exterior protection, and one (1) set of 5" heavy-duty casters
  • Standard Right hand door swing (optional Left hand door swing available, please contact Customer Service for a quote on this feature)
  • Warranty: • Three Years on Parts • One Year Service • Lifetime Technical Support

Controls:

  • Each chamber's temperature is regulated by a separate electronic control consisting of a 4 digit L.E.D. display, ON/OFF key, heat indicator light, increase and decrease keys, built in lock-out features and a series of prompt sequence indicator lights
  • Each control can easily be set to operate in Fahrenheit or Celsius
  • Fail-safe feature "remembers" the operational mode in the event of a power failure. Once power is restored, the warmer will continue where it left off
  • A thermal shut-off system, separate from the electronic controls, is included as an additional safety feature
  • The blanket warming top compartment:
        • The design and operational characteristics of the chamber eliminate the need for a heat circulating fan
        • The electronic control has an adjustable temperature range of 98°F to 200°F (37°C to 93°C)
        • TIMER mode allows the user to program the control to automatically turn on and turn off once during a 24-hour period at a selected time. This enables the blanket warming chamber (only) to be shut off automatically at night to save energy, but to turn on again in the early morning to ensure warm blankets are available
  • The fluids warming lower compartment:
        • Has individual control settings for irrigation fluids (IRR) and intravenous fluids (INJ) to allow for precise temperature regulation
        • IRR temperature may be adjusted from 98°F to 150°F (37°C to 66°C) while the INJ temperature range is 98°F to 104°F (37°C to 40°C)
        • A fan located inside the chamber mixes the air to prevent temperature stratification and to ensure an accurate chamber temperature within +0/-2°F for set points of 98°F to 104°F and within +0/-3°F for set points of 110°F to 150°F
        • An alarm will sound if temperatures exceed 10°F (6°C) above the set-point temperature, and an OVERTEMP indicator will blink indicating an over-temperature condition.
  • Power: 120 V.A.C - 50/60 Hz
  • UL & CSA approved

Dimensions:

  • Compartment Size: 7.7 cubic feet per compartment (total 15.4 cubic feet)
  • Each Compartment Dimensions: 18 7/8" W x 27" D x 26 7/8" H
  • Fluid Compartment Capacity: 72 liters
  • Overall Size: 25 1/4" W x 35" D x 72 3/4" H

Please Note:

  • This item ships motor freight carrier. During the checkout process you will be required to indicate whether your facility requires liftgate or inside delivery services. (These services are described on our shipping information page.) In the order comments please include a name & phone number for the delivery point of contact. Please also include receiving hours and any other delivery requirements or instructions. If additional services necessitate an additional fee, you will be contacted by Customer Service. If you have questions about the motor freight delivery process please contact Customer Service prior to placing your order.

About this Brand

Specifications

Specifications
Manufacturer Pedigo
Overall Height 72.75"
Overall Length 35"
Overall Width 25.25"
Country of Manufacture United States
Item Ships From Washington
GSA Contract Number V797D-40002

Literature 2

pdf
(Size: 55.8 KB)
pdf
(Size: 2.4 MB)
